The hardest part of invisible doors is addressing the self-closing mechanism, the hinge that closes automatically. The Hidden Door Hinge is one of the hardware parts of the invisible door, which is related to the closing and opening effect of the invisible door. Its installation is also important and affects the life expectancy of the invisible door. There are several considerations for the installation of Hidden Door Hinges.
This is the list of contents：
·Installation type
·Note the installation position and number
·Preventing falling fans
·Grasp the gap distance
·Ensure accessories match
Wooden door installation, first the door and door frame strict good, in the door and door frame contact surface groove, in the closed state installation, the two Hidden Door Hinges are fixed with screws on the door and door frame, and then the door open to 90 degrees positioning state.
Aluminum alloy, plastic steel door installation), the first Hidden Door Hinges installed in the door frame, and then open it to the automatically fixed position (i.e. open to 90 degrees position), the door fan into the door frame (closed state), and then fixed in the door fan Hidden Door Hinges can be completed.
If the door is heavy, it is recommended to use three Hidden Door Hinges, generally, two are enough for ordinary doors.
In the Hidden Door Hinge installation skills, the falling fan is the most critical, it refers to the problem of skill in fitting the door, so that the above, etc. slowly become wider, while the gap below slowly becomes narrower, resulting in the opening and closing of the door is not smooth, and even the door will appear to fall, generally this situation is caused by the choice of different specifications of the Hidden Door Hinges.
To make the door look good, the distance between the door panel and the Hidden Door Hinges must be grasped, with a normal gap of 3-5mm.
In the Hidden Door Hinge installation tips, hinge specifications are very important and must be based on the door thickness, length, and width to match. Check that the length width etc. of the Hidden Door Hinge and the link are appropriate and that the total spacing to be left should be the sum of the two minimum spacings if a side panel is shared.
Check that the Hidden Door Hinges and the connected screws and fasteners are matching when linking and that the maximum size available for each type of Hidden Door Hinge is selected according to the different conveyor categories.
The above is the Hidden Door Hinge installation precautions, hope to help you, in fact, Hidden Door Hinge installation as long as a little careful, the difficulty are not too big, just fee labor, if the invisible door with the current smart switch of intelligent equipment, that does not need to install the handle, it is more beautiful.
