D&D Hardware quality Panic Exit Hardware hardware is ANSI grade 1 (500,000 cycle test) .
Our fire rated panic exit hardware hardware has a UL10C three-hour fire rating, is ANSI grade 1.Suitable for Covernment ,Hotel,Education, Healthcare, Apartment building, Hospitality Commercial applications.
The D&D range of architectural locks is manufactured to the highest engineering standards and designed to offer a high price/ performance ratio.
They have been successfully type tested to all the requirements of BS EN 12209/ EN 1634, 240 minutes Fire Rate.
The D&D range of architectural hinges is manufactured to the highest engineering standards and designed to offer a high price/ performance ratio.
They have been successfully type tested to all the requirements of BS EN 1935, ANSI/BHMA,UL 10C, 3 hours Fire Rate.
The D&D range of door closer is designed to offer a high price/ performance ratio.
They have been successfully type tested to all the requirements of BS EN 1154, 90 mins fire rated,UL Certification.
Staircase Escape route - Swing type double metal door without overlap- fire rated – American standard
Door design considerations mainly as below:
1, Where the building and inner door located
2, Direction of the flow of people in the building
3, Number of people the building expecting
4, It is a fire resistant and heat insulated door
Main concern points for this configuration are:
1, Safety
Door opening & closing description:
Outside lever trim retracts latch bolt. Key outside locks or unlocks lever.
Inside vertical rod exit hardware always free for egress.
Door closer self-closing the door anytime it opens.
This configuration is suitable for below applications:
| School |
| Super market | Air-port building |
| 5-stars hotel | Museum | Elderly house | Shopping mall |
| Stadium | Hospital | High-end office building | Hotel |
| Station | Office Building | exhibition center | Government building |
HANGING - Hinge
D&D 4.5x4.5x3.4-2 ball bearing butt hinge can be in grade 201/304/316 stainless steel material, square corner, template drilled, button tipped five knuckles, UL listed (3 hour fire rated), with UL Mark, ANSI/BHMA A156.1 Grade 2 certified, suitable for use on fire/non-fire rated/ smoke check doors up to 120 kg, with suitable screw pack.
SAFETY – Vertical Rod Exit Device
D&D Vertical Rod Exit Device- half-length pressing touch bar with deadlocking latch bolt, non-handed, inside always free to exit by pressing the bar, suitable for doors width from 650mm to 1000mm, door thickness from 44.5mm to 50mm, standard door height is 2100mm (door higher than standard, please contact D&D), suitable for use of External locking attachment (such as lever trim). UL listed (3 hour fire rated), comply to ANSI/BHMA Grade 1. Suitable for use on fire rated doors.
CONTROLING – Door closer
D&D adjustable power size 3-4, suitable for max door width from 950mm to 1100mm, suitable for max door weight from 60kg to 80kg, size L248xW44.5xH72mm, in aluminum material silver finish, UL listed (3 hour fire rated), parallel arm, non-hold open function, adjustable closing and latching speed, standard top jamb, push side installation, packed with suitable screw pack.
PROTECTING – Dust proof socket
D&D Dust proof socket, in stainless steel 304 material, matt finish, size dia25x39mm, for dia 13mm bolt.
OPERATING & SECURING - Lever trim
D&D 4.5x4.5x3.4-2 ball bearing butt hinge can be in grade 201/304/316 stainless steel material, square corner, template drilled, button tipped five knuckles, UL listed (3 hour fire rated), with UL Mark, ANSI/BHMA A156.1 Grade 2 certified, suitable for use on fire/non-fire rated/ smoke check doors up to 120 kg, with suitable screw pack.
Office door - Single leaf swing type wood door- non fire rated – European standard
This configuration is suitable for below applications:
| School | High-class club | Super market | Air port |
| 5-star hotel | Museum | Nursing home | Shopping mall |
| Sport stadium | Hospital | High-class office building | Hotel |
| Station | Office Building | exhibition center | Government building |
Associated door hardware
D&D 2 4”x3”x3.0mm-2 ball bearing butt hinge can be in grade 201/304/316 stainless steel material, square corner, template drilled, button tipped five knuckles, conforming to BS EN 1935-Grade 13, EN1634-260 minutes fire rated, with CE Mark, suitable for use on fire/non-fire rated/ smoke check doors up to 120 kg, with suitable screw pack.
CONTROLLING - Door closer
Adjustable power size 3-4, suitable for max door width from 950mm to 1100mm, suitable for max door weight from 60kg to 80kg, size L248xW44.5xH72mm, in aluminum material silver finish, CE certified (60 minutes fire rated), parallel arm, non-hold open function, adjustable closing and latching speeds, standard top jamb, push side installation, packed with suitable screw pack.
SECURING - Cylinder
D&D single cylinder with thumb turn- cylinder 35/35mm (70mm) 6 pins with 3 differ keys, comply with British Standard EN 1303, packed with fixing screw.
OPERATING - Lever handle
D&D U shape “LEVER HANDLE”, 19*140mm diameter, in grade 304/316 stainless steel material(rust resist grade), SSS finish, on dia53 x 9mm size SSS finish concealed roses fixing with Cylinder escutcheon, comply to EN1906 standard, CLASS 4, with suitable screw pack.
SECURING - Mortise lock
D&D Fire rated Sash Lock - 55mm backset x CTC72mm c/w square front plate, holed for Euro-profile cylinder & 8mm x 8mm follower, Bolt through hardware fixings / Comply with British Standard EN 12209 Grade 3- CE Marked - Fire rated 240 minutes, with suitable screw pack.
Function description: Latch bolt can be operated by lever handles on either side. Deadbolt thrown and retracted from one or from both sides depending on the type of cylinder installed. Cylinder action will operate both deadbolt and latch bolt. Deadbolt 2- turns.
ANCILLARY - Door stop
D&D 30mm diameter x 40mm height, floor mounted door stopper comes with screws for fixing, in SUS304/316 stainless steel material, SSS finish.
Suggestion: If there is a privacy requirement, can equip with a self-closing door closer.
Classroom - Single leaf swing type metal door- non fire rated – American standard
Door design consideration mainly as below:
1, Where the building and inner door located
2, Number of times a door opens and closes
Main concern points for this configuration are:
1, Safety
2, User friendly
Door opening & closing description:
Outside trim locked or unlocked with a key.
Latch bolt operated by inside trim or key outside when locked. Inside trim always free for egress.
Guard bolt deadlocks latch bolt.
This configuration is suitable for below applications:
School
HANGING - Hinge
D&D 2 ball bearing butt hinge can be in grade 201/304/316 stainless steel material, square corner, template drilled, button tipped five knuckles, conforming to UL/cUL (3 hour fire rated), with UL Mark, suitable for use on fire/non-fire rated/ smoke check doors up to 120 kg, with suitable screw pack.
SECURING & OPERATING - Classroom mortise lock
D&D Classroom mortise lock
Outside trim locked or unlocked with a key.
Latch bolt operated by inside trim or key outside when locked. Inside trim always from for egress.
Guard bolt deadlocks latch bolt when outside trim is locked.
PROTECTION - Door stop
D&D 44mm diameter x 25mm height, half-moon type floor mounted comes with screws for fixing, in SUS304/316 stainless steel material, SSS finish, pack with suitable screw pack.
OPERATING - Escutcheon lever trim (indoor trim without cylinder hole)
D&D Escutcheon lever trim, L210xW47mm escutcheon, Lever size Dia22xL140mm, in grade 304 stainless steel material (rust resist grade), SSS finish, with Mortise Cylinder hole on the outside(without cylinder hole on the inside), with suitable screw pack.
OPERATING - Escutcheon lever trim (indoor trim without cylinder hole)
D&D Escutcheon lever trim, L210xW47mm escutcheon, Lever size Dia22xL140mm, in grade 304 stainless steel material (rust resist grade), SSS finish, with Mortise Cylinder hole on the outside(without cylinder hole on the inside), with suitable screw pack.
PROTECTION – Kick plate
D&D Kick plate, size the width of a kick plate 1-1/2” less than door width on single doors and 1” less than door width on pairs of doors. The recommended height of kick plates is 1“ less than the height of the bottom rail, packed with suitable screw pack.
Building owners understand that keeping down maintenance costs necessitates vigilance through charge of building systems to handle support efficiency.
D&D key systems improve control by restricting access through optimized key management to central areas of those buildings. Only the right personnel are authorized minimizing potential misuse of services and possible liability.
Conference room, office, showroom,Stairwells, pipe chases, electrical, rooms, custodial equipment, communicating closets, elevator controls, pipes and HVAC are every area requiring protection , and D&D hardware gets the retrofit capability to secure most of these areas.
Security needs for healthcare centers are more critical than ever. A growing amount of crimes have been committed in practices and hospitals. Concerns about access to health records, pharmaceuticals, acute care centers, operating rooms, bio hazard and lab facilities call for high security systems.
To meet the needs of a fast growing population requiring medical caution many geriatric providers are protecting their centers with high security lock systems to mitigate potential issues in addition to maintaining a safe perimeter to prevent patients or clients by wandering away from their chambers and quarters.
Building owners understand that keeping down maintenance costs necessitates vigilance through charge of building systems to handle support efficiency.
D&D key systems improve control by restricting access through optimized key management to central areas of those buildings.Only the right personnel are authorized minimizing potential misuse of services and possible liability.
Stairwells, pipe chases, electrical, rooms, custodial equipment, communicating closets, elevator controls, pipes and HVAC are every area requiring protection , and D&D hardware gets the retrofit capability to secure most of these areas.
D&D Hardware has been at the forefront of driving key innovation within the hospitality and entertainment industries by providing hotels and properties with products that increase guest satisfaction, thereby increasing their overall value. Our team of experts continues to use the most advanced technologies to offer security, compliance and peace of mind to both hospitality providers and their guests.
D&D provides the hospitality door hardware solutions to help you create a welcoming and open space that is also secure, quiet, accessible and energy efficient.
Most government entities possess a wonderful demand for security along with a superior degree of flexibility. The system has to be field proven, safe and easy to administrate.
Police stations, courts, fire & emergency first responders are all services with very specific security requirements.
It is important that the system can be accommodated to accommodate the situation and also some other hazards that they may encounter.
Military facilities cover a broad selection of activities, large geographical footprint, and buildings using different operational requirements. Offices, training centres and exercise are as need high security protection against unauthorized access...
Entertainment & Leisure Facilities Stadiums, arenas and theaters serve many people with exceptional access and egress needs together with time and volume considerations that dictate the access rights provided.
School facilities The buildings have to be shielded unauthorized people, theft or vandalism.
Sports centers Sports centers have rental locations and luxury boxes that require suitable but detailed access control.
The right security in the right place With D&D’s product solutions, you have the right security while in the right place.
Universities Higher educational institutions are available to the population they serve and may become the aim for crimes of opportunity.
Welcome To Contact Us For Better Margin
D&D Hardware has established long business relations with customers from America, Europe, Middle East and Asia, benefit from product certification, expertise knowledge, quality assurance, competitive pricing, customization ability and great service.
Welcome to contact us for better margin.
