Introduction to Hidden Door Hinges

Do you know what a Door Hidden Hinge is? Have you ever heard of them? A Hidden Door Hinge is an invisible hinge. They are used to open and close doors and are an indispensable accessory for doors. To give you a clearer understanding of Hidden Door Hinge, I would like to give you a detailed introduction today.

This is the list of contents：

·Types

·Advantages

·Cautions

Types

• Common hinges: used for cupboard doors, windows, doors, etc. Materials are iron, copper, and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After installing ordinary Hidden Door Hinges, various touch beads must be fitted again, otherwise, the wind will blow the door panels.

• Pipe hinges: also called spring hinges. Mainly used for the connection of furniture door panels, it generally requires a plate thickness of 16￣20 mm. Materials include galvanized iron and zinc alloy. The spring-loaded Hidden Door Hinge comes with an adjustment screw that allows the height and thickness of the plate to be adjusted up and down, left and right. One of its features is that it can be matched to the cabinet door opening angle according to the space. In addition to the general 90-degree angle, 127-degree, 144 degree and 165-degree hinges are available to match, so that various cabinet doors have the corresponding extension.

• Door hinges: are divided into common and bearing types, the common type having been described earlier. Bearing type from the material can be divided into brass and stainless steel quality. From the current consumption situation, the choice of brass bearing hidden door hinges is more, because of its beautiful, bright style, moderate price, and equipped with screws.

• Other hinges: there are glass hinges, countertop hinges, and flip door hinges. Glass hinges are used for the installation of frameless glass cupboard doors, requiring a glass thickness of no more than 5 - 6 mm.

Advantages

• Hidden door hinges are not visible when the door is closed and are invisible when viewed from the outside, making them simple and aesthetically pleasing.

• Hidden Door Hinges are not limited by the thickness of the panel and have a better load-bearing capacity.

• The doors can be opened and closed freely and the opposing doors do not collide with each other.

• The Hidden Door Hinge can limit the force to avoid collision caused by the door opening too much.

• Hidden door hinges can add damping and three-dimensional adjustment functions for greater versatility.

Cautions

• Before installation, check that the Hidden Door Hinges match the door and window frames and sashes.

• Check that the slot matches the height, width, and thickness of the Hidden Door Hinge.

• Check whether the Hidden Door Hinges are matched with the screws and fasteners attached to them.

• When installing, ensure that the axes of the Hidden Door Hinges on the same fan are on the same plumb line to avoid the door or window fan from bouncing.

The types of Hidden Door Hinge and precautions have been introduced, I believe that everyone must be very clear now. Every door must be hinged if it is to open and close properly. Hidden Door Hinges are more aesthetically pleasing. We hope that you will be able to install Hidden Door Hinges yourself. Create a beautiful home for yourself.
