BS EN1303 Cylinders for locks

Views:95     Author:Site Editor     Publish Time: 2017-11-28      Origin:Site

Lock Cylinder-D&D Hardware

1. Category of use


One category is identified.



Grade 1: For use by people with a high incentive to exercise care and with a small chance of mis-use.



2. Durability


Three grades are identified according to the number of test cycles achieved.



Grade 4 : 25 000 Cycles


Grade 5 : 50 000 Cycles


Grade 6 : 100000 Cycles




3. Door mass


One grade is identified:


Grade 0 : No requirement



4. Fire resistance


Two grades are identified:


Grade 0 : Not suitable for fire/smoke resistant door assemblies


Grade 1 : Suitable for fire/smoke resistant door assemblies subject to satisfactory assessment of the contribution of the cylinder to the fire resistance of the specified fire/smoke door assemblies. Such assessment is beyond the scope of this European standard (see EN 1634-1).box 4), it must be possible to demonstrate compliance with the Essential Requirements of the Construction Products(Amendments)Regulations.



5. Safety


One grade is identified:


Grade 0 : No requirement



6. Corrosion and Temperature Resistance


Four grades are identified according to EN 1670:


Grade 0 : No corrosion or temperature resistance requirements


Grade A : BS EN 1670 Grade 3 corrosion resistance (96 hours NSS): no temperature resistance requirements


Grade B :No corrosion resistance: resistance to -20/+80 C temperature extremes


Grade C :BS EN 1670 Grade 3 corrision resistance: resistance to -20/+80C temperature extremes


No distinction is made between the inside and the outside of either the cylinder and/or the door. On completion of the test, the cylinder must operate.




7. Key related security


Six grades are identified and the principal requirements are summarised in Table 1`below :


Grade

1

2

3

4

5

6

Minimum number of effective differs

100

300

15,000

30,000

30,000

100,000

Minimum number of movaable levers, pins, discs etc

2

3

5

5

6

6

Minimum number of movaable levers, pins, discs etc

Yes

Yes

No

No

No

No

Coding on key should disclose close combination

2.5Nm

5Nm

15Nm

15Nm

15Nm

15Nm



8. Attack resistance


Three grades are identified and the principle requirements are summarised in table 2 below:

Resistance to drilling
(nett drilling time )

Grade

0

1

2

-

3/5

5/10 mins

Resistance to chisel attack (number of defined belows)

-

30

40

Resistance to twisting attack (number of defined twists)

-

20

30

Resistance to plug/cylinder extraction (pull load)

-

15N

15kN

Torque resistance of plug/cylinder

-

20Nm

30Nm



Keyed To differ

Cylinders to differ are all operated by individual keys all different to each other



Keyed Alike Suites(KA)

In keyed alike arrangements all cylinders are operated by the same key. This gives an arrangement where one key will open a group of locks. Not to be confused with a master keyed suite (see below). Cylinders can also be keyed alike to the euro profile, oval and rim cylinders. This is useful where a combination of cylinder mortice lock cases and cylinder rim nightlatches are being used.


Common Entrance Suite

Common entrance (or flat enterance) suites are designed to enable a tenant to use the same key for his own private doors as well as doors common to other residents within the same buildings. The common to other residents within any master key suite.



Master key Suites(MK)

In Master key suites, a group of cylinders, each equipped with an individual servent key, is also operated by one special key known as the master key. keyed alike groups can also be incorporated into any master key suite.



Grand Mater Key Suites(GMK)

Grand master key suites are used when it is necessary to have more than one master key group. These groups are referred to as sub suites.In these instances all cylinders irrespective of their sub suite, are controlled byone key as the grand master key.







As a professional door cylinder manufacturer in China, we provide customers various exterior and interior door lock cylinder. Our door cylinders are high-quality, durable, anti-rust and textured. The cylinders we provide are suitable for wooden door, metal door, fire rated door, double door, single door, steel door of commercial or residential application.



All our products strictly according to international Standard, such as the ANSI, BS EN/CE, UL, BHMA standard.
