When it comes to doors, hinges is very important. Their style and functionality have a huge effect on the performance of your doors. The good news is that a wide range of hinge options are available, so there's an excellent chance there's a hinge out there that's right for your application.
SELECT THE PROPER WEIGHT AND BEARING STRUCTURE
Hinges are placed into three groups because of the various door sizes and weights:
Standard Weight –– Ball Bearing
Example –– DDSS001, 41/2”x 41/2” (114.3 x 114.3 mm), US32D
Heavy Duty- Ball Bearing
Example ––DDSS002, 5”x 5”(127 x 127 mm), US32D
Standard Weight –– Plain Bearing
Example ––DDSS004, 41/2”x 4”(114 x 102 mm), US32D
There are two factors that determine the weight and structure of the hinge: weight of the door and frequency of use. It is advisable to include the approximate weight of additional hardware that will be installed on the door.
THICKNESS OF DOOR | WIDTH OF DOOR | HEIGHT OF HINGE |
13/18” (35 mm) Door | To 32” (813mm ) | 31/2” (89 mm) |
13/8” (35 mm) Door | 32” to 36” (813 to 914 mm) | 4” (102 mm) |
13/4” (45 mm) Door | To 36” (914 mm) | 41/2” (114 mm) |
13/4” (45 mm) Door | 36” to 48” (914 to 1219 mm) | 5” (127 mm) |
13/4” (45 mm) Door | Over 48” (1219 mm) | 6” (152 mm) |
2'', 21/4” & 21/2” Door (51, 57 & 64 mm) | To 42” (1067 mm) | 5” Heavy Weight(127 mm) |
2'', 21/4” & 21/2”Door (51, 57 & 64 mm) | Over 42” (1067 mm) | 6” Heavy Weight(152 mm) |
There are three dimensions to know in order to determine the minimum width of the hinge: door thickness, backset and clearance required.
1.When figuring the calculations for a wood door and wood frame, the door is flush with the casing or face of the frame. When figuring the calculations for a wood or metal door with a hollow metal frame, the door is inset approximately 1/8” (3.2 mm).
2.For doors up to 2 1/4” (57 mm) thick, the hinge is set back 1/4” (6.4mm) from the back face of the door.
3.For doors over 21/4” (57 mm) thick, the hinge is set back 3/8” (9.5 mm) from the back face of the door.
Once these dimensions are known, the formula can then be applied. Take the door thickness, minus the backset, times two, plus the clearance required. If the hinge size is not standard, then go to the next larger hinge width. If the width of the hinge is greater than the height of the hinge (example: 41/2” x 6” (114 x 152 mm) this is referred to as a Wide Throw Hinge. This would apply only to full mortise hinges.
GUIDELINES FOR FREQUENCY OF DOOR USAGE
DOOR SITUATION AND ESTIMATED NUMBER OF OPERATIONS | |
Daily | |
High frequency heavy duty situations: | |
Large departmental store entrances | 5,000 |
Large office building entrance | 4,000 |
Cinema or theatre entrance | 1,300 |
School entrance | 1,250 |
Entrance door to school toilets | 1,250 |
City centre shop entrance | 1,000 |
Large city bank entrance | 1,000 |
School corridor fire door | 600 |
Town bank entrance | 500 |
City centre restaurant entrancce | 500 |
Large office corridor fire door | 450 |
Large office or factory toilets entrance | 400 |
Hospital ward door | 350 |
Medium frequency medium duty situatuins: | |
School classroom door | 80 |
Office door | 75 |
Store toilet door | 60 |
Dwelling rear or side entrance | 15 |
Dwelling front entrance | 12 |
Low frequency light duty situations: | |
Dwelling living room communications doors | 30 |
Dwelling bathroom/toilet door | 20 |
Dwelling cupboard door | 12 |
Dwelling bedroom door | 9 |
Dwelling wardrobe / closet door | 6 |
Dwelling cabinet furniture door | 5 |
